Last weekend, I took on a small project – I tried to figure out what thickness of sheet metal is used in cars. Sounds simple, right? Well, not quite.
How It All Started
I needed to weld a patch onto an old pickup truck. A classic scenario — rust around the wheel arch. I went to a local auto parts store and picked up a panel that seemed like it would fit. But I wasn’t sure if the thickness matched the original metal. I didn’t want to just slap it on and end up with a weak spot on the body.
I grabbed my digital caliper — the kind that can measure with high precision. Measuring the metal on the car body wasn’t easy — the paint and rust got in the way. I cleaned the area as much as I could and took my measurements. Then I measured the new patch panel and noted that as well.
Thickness in Inches and Gauge Conversion
This is where things got a bit confusing. The measurements were in inches, but in the automotive world, sheet metal thickness is usually expressed in gauge. So I went online and found tables to convert inches to steel gauge.
Turns out, automotive sheet metal most commonly ranges from 18 to 22 gauge. My measurements fell within that range, but I wanted to double-check.
How I Verified It
I have a set of drill bits that I use as gauge pins for another hobby. I started with the smallest and moved up to larger sizes until I found one that matched my measurements precisely.
To be absolutely sure, I did a test weld. I took a piece of the new panel and welded it to a scrap piece of metal that matched the car body’s thickness exactly. I adjusted the welder settings to get a strong weld without burning through. If the new panel had been significantly thinner, the weld would have been weak or burned through.
The Result
After the test, I was confident in the thickness and moved forward with the repair: cut out the rusted section, shaped the new panel, and carefully welded it in. I’m happy with the result — the pickup looks much better now.
What I Learned
- Automotive sheet metal is most commonly between 18 and 22 gauge.
- A digital caliper is an indispensable tool.
- Don’t rely solely on online tables — always do a test weld.
So, determining the right gauge isn’t rocket science, but it does require attention to detail and a bit of effort. I hope my experience helps anyone else dealing with a rusty car body.
