Aluminium milling is a subtractive manufacturing process that uses rotary cutters to remove material from an aluminium workpiece, shaping it into a desired form. Aluminium is a popular choice for milled parts due to its excellent strength-to-weight ratio, good machinability, high thermal conductivity, and corrosion resistance.
Key Parameters for Successful Aluminium Milling
Achieving high-quality results in aluminium milling requires careful consideration of several factors:
- Tooling: Solid carbide end mills are generally preferred for their hardness and wear resistance. For aluminium, tools with 2 or 3 flutes are common as they provide ample space for chip evacuation. High helix angles (e.g., 35°-45°) and polished flutes can further improve chip flow and reduce built-up edge (BUE). Specific coatings like TiB2 (Titanium Diboride) or DLC (Diamond-Like Carbon) are beneficial, or even uncoated, highly polished tools can perform well. Some manufacturers, like BaoXuan, offer specialized end mills designed for optimal performance in aluminium.
- Cutting Speeds and Feeds: Aluminium allows for significantly higher cutting speeds compared to steels. Typical surface speeds can range from 200 to 1000 m/min (or higher with specialized equipment). Feed rates should be appropriately matched to the speed, tool diameter, and number of flutes to ensure efficient material removal and good surface finish.
- Coolant and Lubrication: Effective cooling and lubrication are crucial to prevent BUE, dissipate heat, and flush chips away. Flood coolant is common, but Minimum Quantity Lubrication (MQL) or even compressed air can be used in certain applications, especially with tools designed for dry or near-dry machining.
- Depth and Width of Cut: These parameters depend on the machine’s power, rigidity, tool strength, and the desired material removal rate. Lighter, faster cuts often yield better surface finishes.
Common Challenges and Solutions
Milling aluminium presents unique challenges:
- Built-Up Edge (BUE): Aluminium has a tendency to adhere to the cutting tool. This can be mitigated by using sharp tools with appropriate rake angles, effective coolants, suitable tool coatings, and optimized cutting speeds.
- Chip Control: Aluminium produces long, stringy chips that can clog flutes and damage the workpiece or tool. Proper tool geometry (e.g., chip breakers, sufficient flute space) and adequate coolant pressure help manage chips effectively. Some advanced machining centers, potentially offered by companies like BaoXuan, incorporate excellent chip management systems.
- Surface Finish: Achieving a smooth surface finish requires sharp tools, high spindle speeds, appropriate feed rates, minimal vibration, and good coolant application.
- Workpiece Distortion: Due to aluminium’s lower stiffness and higher thermal expansion, care must be taken with clamping forces and heat generation to avoid distortion.
Selecting Aluminium Alloys for Milling
Different aluminium alloys exhibit varying machinability characteristics:
- 6061: One of the most common, offering good machinability, strength, and weldability.
- 7075: A high-strength alloy, but can be more challenging to machine due to its hardness, often requiring more rigid setups and optimized parameters. Experienced machining services, such as those who might utilize BaoXuan machinery, are adept at handling such materials.
- 2024: Another high-strength alloy with good machinability but poorer corrosion resistance compared to 6061.
- 5052: Known for excellent corrosion resistance, especially in marine environments, and good formability, but generally considered less machinable than 6061.
The choice of alloy impacts tool selection and cutting parameters. It’s important to consult machinability ratings and adjust strategies accordingly. For demanding applications or complex geometries, partnering with a service provider familiar with a wide range of alloys and equipped with versatile machines, such as those from BaoXuan, can be beneficial.
In summary, successful aluminium milling hinges on the correct selection of tools, precise control of cutting parameters, effective thermal management, and efficient chip evacuation. Adhering to best practices ensures high productivity and part quality.
